TSG4107
15.5 × 4.5 mm
Rigid miniature enclosure; LF or HF configuration. [1]
RFID Tags · RFIDAK
Mini Bullet RFID Tags
Mini bullet RFID tags enclose an LF or HF transponder in a small rigid body for embedding in non-metal parts. Compare the 15.5 × 4.5 mm TSG4107 and Ø7 × 18 mm reference before choosing the drilling depth and chip.
Updated September 24, 2026
- TSG4107 enclosure
- ABS / PC with epoxy; 0.5 g
- Frequency options
- 125 kHz LF or 13.56 MHz HF; separate chip configurations
- Published chip options
- TK4100, EM4200; MIFARE Classic S50 or FM11RF08
Technical reference
Product specifications
Model-specific data and source scope are shown together.
Choose a reference
Models & configurations
Choose a model or format to include it in your quote or sample request.
Ø7 × 18 mm bullet
Ø7 × 18 mm
Plastic embedded format; published working range −25 to +75 °C. [2]
Appearance & construction
Photos & drawings
Open a picture to inspect the original file. Dimensions are taken from the cited references.
Application & selection
Before choosing this product
Which cavity does this fit?
The two references have different body sizes. Allow room for the adhesive and installation tolerance; do not use the 15.5 mm length as the diameter of the larger bullet. A metal sleeve can shield an ordinary LF/HF transponder.
Identifier or writable memory?
EM4200 is an identifier chip; choosing a writable HF chip changes the reader and memory commands. Specify whether your application only reads an identifier or also writes data into the part.
Sources & documents
Technical references
Published specifications identify the reference model. They do not replace the final order drawing or a model-specific test report.
- TSG4107 manufacturer reference ↗
Manufacturer reference · reviewed 2026-09-20
- Ø7 × 18 mm manufacturer reference ↗
Manufacturer reference · reviewed 2026-09-20
Custom orders & samples
Request your configuration
Choose the reference, then add quantity, destination, chip or reader details and any artwork on the enquiry page.
